26
Colors 16.7 million
Brightness(typical) LCD panel: 250 nits
ResistiveTouch: 200 nits
Response time - total (typical) 5 msec
Viewing angle (typical) Horizontal: ±80° or 160° total
Contrast ratio (typical) 1000:1
Input video format Analog VGA
Input video signal connector D-Sub 15-Pin VGA type
Input frequency Horizontal: 31.5-60.2 kHz
Vertical: 56.3-75 Hz
Power supply Internal AC, Optional external DC (power brick)
Input voltage AC: 100-240 VAC, 50/60 Hz
DC: +12VDC ±5%
Input connector AC: IEC 60320 C6
DC: Coaxial power jack (2 mm pin diameter, 6.4 mm barrel diameter,
8.8 mm barrel length)
Power consumption (typical) 35 W
Options 3-Tracks Magnetic Stripe Reader, USB interface
VFD Customer Display, 2 lines with 20 characters per line, Serial
interface
Wall mount or celling mount brackets
Temperature Operating: 0°C to 40°C (32°F to 104°F)
Stora
e: -20°C to 60°C (-4°F to 140°F)
Humidity(noncondensing) Operating: 20%-80%
Storage: 10%-90%
Weight Actual with stand: 10.6 lb (4.8 kg)
Actual without stand: 7.3 lb (3.3 k
)
Shipping with stand: 15.4 lb (7.0 kg)
Shipping box dimensions(W x D
x H)
16.54" (420 mm) x 14.96" (380 mm) x 10.24" (260 mm)
Backli
ht lamp life Typical 30,000 hours to half bri
htness
MTBF 50,000 hours demonstrated
On-screen display (OSD) Controls (side): menu, up, down, select, power
Settings: contrast, brightness, H/V position, RGB (color temp), clock,
phase, recall
Languages: English, German, Spanish, Japanese, French
Lockouts: power, user controls
Stand options Removable
Mounting options 75 mm VESA mount
Threaded-through mounting holes, under stand
