Sinocan T06-19 - T06-19 Specification


27
T06-19 Touch Monitor Specification
Model T06-19
Form factor Desktop
Enclosure color Black
Diagonal size 19.0"
Aspect ratio 4:03
Useful screen area Horizontal: 12.0" (304 mm)
Vertical: 9.0" (228 mm)
Monitor dimensions (with stand) Width: 13.8" (350 mm) Height: 12.2" (310 mm) Depth: 6.9" (175
mm)
Dimensions vary with stand position and options selected
Native (optimal) resolution 1280 x 1024 @ 85 Hz
Other supported resolutions 1024 x 768 @ 60, 65 Hz (Sun), 70 or 75 Hz
832 x 624 @ 75 Hz (Mac)
800 x 600 @ 56, 60, 72 or 75 Hz
720 x 400 @ 0 Hz
640 x 480 @ 60, 66 Hz (Mac), 72 or 75 Hz
640 x 350 @ 70 Hz
Colors 16.7 million
Brightness(typical) LCD panel: 250 nits
ResistiveTouch: 200 nits
Response time - total (typical) 5 msec
Viewing angle (typical) Horizontal: ±80° or 160° total
Contrast ratio (typical) 1000:01:00
Input video format Analog VGA
Input video signal connector D-Sub 15-Pin VGA type
Input frequency Horizontal: 31.5-60.2 kHz
Vertical: 56.3-75 Hz
Power supply Internal AC, Optional external DC (power brick)
Input voltage AC: 100-240 VAC, 50/60 Hz
DC: +12VDC ±5%
Input connector AC: IEC 60320 C6
DC: Coaxial power jack (2 mm pin diameter, 6.4 mm barrel
diameter, 8.8 mm barrel length)
Power consumption (typical) 40 W
Options 3-Tracks Magnetic Stripe Reader, USB interface
VFD Customer Display, 2 lines with 20 characters per line, Serial
interface
Wall mount or cellin
g
mount brackets
Temperature Operating: 0°C to 40°C (32°F to 104°F)
Storage: -20°C to 60°C (-4°F to 140°F)
Humidity(noncondensing) Operating: 20%-80%
Stora
g
e: 10%-90%
Weight Actual with stand: 10.6 lb (4.8 kg)
