Sinocan T06-19 - T06-22 W Specification


28
Actual without stand: 7.3 lb (3.3 kg)
Shipping with stand: 15.4 lb (7.0 kg)
Shippin
g
box dimensions(W x D
x H)
16.54" (420 mm) x 14.96" (380 mm) x 10.24" (260 mm)
Optional product coverage Advance Unit Replacement program (North America only)
Backlight lamp life Typical 30,000 hours to half brightness
MTBF 50,000 hours demonstrated
On-screen display (OSD) Controls (side): menu, up, down, select, power
Settings: contrast, brightness, H/V position, RGB (color temp),
clock, phase, recall
Languages: English, German, Spanish, Japanese, French
Lockouts: power, user controls
Stand options Removable
Mounting options 75 mm VESA mount
Threaded-through mounting holes, under stand


T06-22W Touch Monitor Specification
Model T06-22W
Form factor Desktop
Enclosure color Black
Diagonal size 22"
Aspect ratio 16:10
Useful screen area Horizontal: 12.0" (304 mm)
Vertical: 9.0" (228 mm)
Monitor dimensions (with stand) Width: 13.8" (350 mm) Height: 12.2" (310 mm) Depth: 6.9" (175
mm)
Dimensions vary with stand position and options selected
Native (optimal) resolution 1680 x 1050 @ 85 Hz
Other supported resolutions 1024 x 768 @ 60, 65 Hz (Sun), 70 or 75 Hz
832 x 624 @ 75 Hz (Mac)
800 x 600 @ 56, 60, 72 or 75 Hz
720 x 400 @ 0 Hz
640 x 480 @ 60, 66 Hz (Mac), 72 or 75 Hz
640 x 350 @ 70 Hz
Colors 16.7 million
Brightness(typical) LCD panel: 300 nits
ResistiveTouch: 250 nits
Response time - total (typical) 5 msec
V
iewin
g
an
g
le (typical) Horizontal: ±85° or 170° total
Contrast ratio (typical) 1000:01:00
Input video format Analog VGA
Input video signal connector D-Sub 15-Pin VGA type, DVI type option
Input frequenc
y
Horizontal: 31.5-60.2 kHz
