Antenna connection
VHF TV ANTENNA
UHF TV ANTENNA
75 OHM COAXIAL CABLE
300 OHM FLAT CABLE
To TV ANTENNA JACK
300 OHM
75 OHM ADAPTOR
75 OHM DIN
-5-
ON-OFF Power
Connect the AC adapter to the household power outlet.
Press the main power switch on the set board. The indicator will switch on.
Thereafter press the [STANDBY] button to open or switch the receiver off.
NOTE:
Switch the receiver off and unplug the AC adapter from the
power outlet when not using it for a long period of time.
Connect the 75 OHM coaxial cable from the antenna to the antenna socket on the rear
panel, as shown above.
NOTES:
For better reception, especially in outlying areas or where ghost effect or interference occur,
an external roof-mounted antenna is recommended.
For UHF TV reception, use the specified UHF antenna. Consult a local AV technician.
When using 300 OHM flat cable, a 300 OHM-75 OHM adapter should be used for a
proper connection to the antenna jack (The adaptor is not supplied).
