SINTERIT POWDER HANDLING STATION - Page 28

24. If the whole powder has been sifted (you cannot see it in the Powder Chamber and on the Sieve), you can turn off
the Sifting module
11
faster by pressing the SIFTING ON/OFF button
14
on the Control panel.
• If the powder is still in the Powder Feeding Screw
23
, you should turn on the vacuum cleaner and wait for emptying
the Powder Chamber by the Powder Feeding Screw
23
and then switch off the vacuum cleaner.
• If the time has ended and the powder is still in the Powder Feeding Screw
23
, you can turn the sifting on again by
pressing the SIFTING ON/OFF button.
• Opening the Sifting module door switches off the mechanism
23
, and the Sifting module
11
stops working. Closing
the door does not automatically turn on the Sifting module again (the SIFTING ON/OFF button must be turned on
again if necessary).
25. For checking whether the whole powder has been sifted:
25.a. Open the door of the Sifting module
11
and tapping the exible tube of the sieve
28
so that the powder from the
walls falls on the Vibrating Sieve
30
(image 34a).
25.b. Remove the sieve locking pin and unfasten the clamping ring
29
(image 34b).
25.c. Lift and attach the Flexible tube with the ange
28
to the magnetic holders of the sieve ange
27
. Put a clamping
ring on the ange so that it does not fall on the sieve
30
(image 34c).
25.d. Check whether there is still any powder in the sieve (image 34d).
25.e. If the powder is still in the sieve
30
, lower the Flexible tube with the sieve ange
28
, put on the clamping ring
29
,
lock it with a locking pin and close the door. Switch on the sifting with the SIFTING ON/OFF button.
a. Tapping the sieve exible tube to remove from the powder. b. Remove the pin and unfasten the clamping ring.
c. Attach the ange of the sieve to the magnetic holders. d. Check if there is powder in the sieve.
27 | POWDER HANDLING STATION Manual
