7 | Page
ELECTRICAL INSTALLATION
THE FOLLOWING ELECTRIC INSTRUCTIONS ARE FOR U.S. CUSTOMERS
CAUTION: Breaker must remain off until installation is complete.
SERIOUS
BODILY
INJURY OR DEATH COULD OCCUR IF YOU IGNORE THIS WARNING.
SioGreen products must be installed by a licensed and qualified electrician in
accordance with all applicable national, state, and local electrical codes
depending on country.
Before installing this product, ensure that the home has sufficient electrical
power available to handle the maximum amperage load of the applicable
model.
IMPORTANT NOTES:
These units will require 2 sets of wire (see wiring diagram), 2 ground wires
and 2 breakers. Please see specifications by model and wiring diagram for
additional information.
Specifications by Model (U.S.)
NUMBER
KW
BREAKER
POWER
WIRE
Step 1: Remove cover of the water heater carefully and locate the electrical
disconnect breaker on the bottom left hand corner facing the unit.
Step 2: Use the correct wire gauge that meets all NEC or country of installation
guidelines based on the size of the breakers used to feed the unit and the
length of the wire run. Then run the set of wires from the home’s main panel
to the tankless water heater. (See above chart for minimum wire size) This
minimum wire size is based on maximum of 50’ of length.
Step 3: Take each wire pair and connect them to one breaker (see wiring
diagram). Make sure that each breaker is connected with one red wire and
one black wire.
