24
69 Screw M4X12 WD01-00068
70 Belt exhaust WD01-00069
71 Collector mounting shaft WD01-00070
72 Hex screw M5×20 WD01-00071
73 Belt mounting plate WD01-00072
74 End cap WD01-00073
75 Mains lead WD01-00074
76 Strain relief WD01-00075
77 Preventer plate WD01-00076
79 Relay WD01-00077
81 Left end cap WD01-00078
82 Key 5X5X15 WD01-00079
83 Washer WD01-00080
84 Screw M6x16 WD01-00081
85 Sanding disc 150 grit 06837
85 Sanding disc 120 grit 06839
85 Sanding disc 60 grit 06841
86 Disc cover WD01-00082
87 Screw M4×10 WD01-00083
88 Angle pointer WD01-00084
89 Disc left support WD01-00085
90 Handle assembly WD01-00086
91 Disc work table WD01-00087
92 Miter gauge bar WD01-00088
93 Miter gauge WD01-00089
94 Disc right support WD01-00090
95 Bearing 6203RZ WD01-00091
96 Rotor WD01-00092
97 Screw M5×180 WD01-00093
98 Stator WD01-00094
99 Hex nut M5 WD01-00095
100 Motor cover WD01-00096
103 Switch WD01-00097
104 Tube connector WD01-00098
105 Capacitor support1 WD01-00099
5
Do not leave the machine unattended when in use. Switch the machine off and
unplug from the mains supply before leaving the work area.
Do not allow children or animals near the belt disc sander, particularly when in use.
Ensure that the belt disc sander is correctly turned off when not in use and store in a
safe, dry area, out of reach of children.
Do not unplug the belt disc sander to switch it off - always use the on/off switch.
ALWAYS locate belt disc sander on a stable and level surface.
Never stand on the belt disc sander.
DO NOT dismantle or tamper with the belt disc sander, as this may be dangerous
and will invalidate the warranty.
Always ensure that the belt / disc sander is turned off and that the mains lead is re-
moved from the supply during all cleaning and maintenance procedures, and
when changing the disc or tracking / changing the belt.
WARNING: Risk of Electric Shock!
Use only the electrical power (voltage and frequency) specified on the model plate
of the belt disc sander. If in doubt contact the manufacturer.
Use only a three-prong, grounded outlet and where required.
ALWAYS unplug the belt disc sander when not in use.
Always wear approved eye protection.
Always wear respiratory protection.
it is advisable to ensure the operator as well as those in the area wear ear protection,
particularly during extended periods of use.
Never wear gloves, neck-ties, jewellery or loose clothing, and always contain long
hair during operation.
Support the work-piece with the mitre gauge, backstop or worktable.
Maintain 1/16” maximum distance between table and sanding belt / disc.
Avoid kickback by sanding in accordance with the directional arrows.
Always mount the sander securely on a firm level surface.
Do not expose the sander to rain or moisture.
Always disconnect the sander from the mains supply before making repairs or adjust-
ments.
Do not move or handle the machine when it is running.
If a problem with the belt disc sander is experienced, or if the mains lead or plug be-
come damaged, contact your distributor for repair.
If the charger is used in a place of work all rules and laws etc. relating to the use of
portable electrical appliances should be followed.
SAFETY INSTRUCTIONS….cont
