SIP B13-5 - 4 Collar

Parts List
13
1 V-BELT
2 Guard w/labels
3 Retaining Spring
4 Ball Bearing x 2
5 Pulley Insert
6 Spindle Pulley
7 Spindle Pulley Nut
8 Motor Pulley
9 Screw Set Bolt
10 Centre Pulley
11 Pivot Idler
12 Ball Bearing
13 Ball Bearing
14 Collar Stop
15 Stop Rod
16 Ball Bearing
17 Shaft Spindle
18 Arbor
19 Chuck
20 Chuck Key
21 Key Drift
22 Base
23 Column
24 Rack
25 Table Support
26 Table
27 Column Clamp
28 Table Clamp
29 Column Support
30 Cranking Handle
31 Helical Gear
32 Worm Gear
33 Pin
34 Column Collar
35 Table Arm
36 Rubber Bush
37 Foam Washer
38 Motor
39 Motor Mount
40 Motor Support
41 Motor Adj. Knob
42 Belt Tension Handle
43 Handle Knob
44 Handle Rod
45 Shaft Pinion
46 Ring Depth w scale
47 Lock depth screw
48 Switch Box
49 NVR Switch
50 Light Switch
51 Set Screw
52 Spring Retainer
53 Tension Spring
54 Spring Cap
55 Adjusting Lever
1
2
11
12
8
9
10
6
7
4
5
36
3
21
13
16
17
18
19
20
15
14
37
}
B13-15 only
