SIP B13-5 - 3 Spindle

Technical Specifications
5
MODEL B13-5 B16-5 B16-16 F16-16 B16-16L F16-16L F25-16 F32-12
A HEIGHT
(MM)
B MAX DIST.
CHUCK TO
BASE (MM)
C MAX DIST.
CHUCK TO
TABLE (MM)
D SPINDLE
TRAVEL
(MM)
1 SPEED
(RPM)
2 MOTOR
(HP)
3 SPINDLE
TAPER
4 COLLAR
DIAMETER
(MM)
5 DRILL
CAPACITY
(HP)
6 TABLE
SIZE
(MM)
7 COLUMN
DIAMETER
(MM)
8
BASE
SIZE
(MM)
9 WEIGHT
(KG)
DIMENSIONSTECHNICAL SPECIFICATIONS (REFER TO DRAWING ON PAGE 4)
580 850 1000 1640 1060 1630 1640 1710
245 490 548 727 600 1154 1136 1075
165 370 371 727 350 668 640 595
50 60 80 80 80 80 80 120
5 5 16 16 16 16 16 16
(500-2500) (460-2480) (190-3000) (190-3000) (190-3000) (190-3000) (160-3000) (120-3480)
1/2 1/2 3/4 3/4 3/4 3/4 1.5 2
JT33 MT2 MT2 MT2 MT2 MT2 MT3 MT4
48 55 55 55 60 60 80 75
0.8-13 3-16 3-16 3-16 3-18 3-18 3-25 5-32
165 x 164 198 x 196 300MM ROUND 290 x 290 290 x 290
300MM ROUND 425 x 475
48 59.5 73 73 73 73 80 92
300 x 200 346 x 211 450 x 300 456 x 305 456 x 305 456 x 305 498 x 350 620 x 420
21 33 60 63 63 70 91 140
