SPIDER
11
12
10
11
9
1
3 2
4 7
8
5 6
1. Rotore laterale
2. Supporto per forche a molla
3. Forche a molla
4. Ruota di sostegno
5. Gamba di sostegno
6. Protezione
7. Protezione del giunto cardanico
8. Tubo idraulico
9. Cilindro idraulico
10. Elemento di blocco
11. Filo di trazione
12. Giunto del rotore
