SPIDER
11
12
10
11
9
1
3 2
4 7
8
5 6
1. Tête rotative latérale
2. Support de dent à ressort
3. Dent à ressort
4. Roue de soutien
5. Chandelle
6. Protection
7. Protection de l'arbre de transmission
8. Tube hydraulique
9. Vérin hydraulique
10. Oreille de verrouillage
11. Corde tirée
12. Joint de la tête rotative
