When using your starter / charger, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, personal injury and / or damage to the starter / charger.
Read all of these instructions before operating the charger and save this user manual for
future reference.
SIP recommends that the starter / charger should not be modified or used for any application
other than that for which it was designed.
This starter / charger is designed for the charging of normal lead acid, sealed, AGM, gel and
Ca/Ca batteries.
It should not be used to recharge NICAD or any other type of battery.
It should not be used to recharge non-rechargeable batteries; To do so may cause fire,
electric shock, etc.
If you are unsure of its relative applications do not hesitate to contact us and we will be
more than happy to advise you.
The starter / charger is designed to be powered from a 220 - 240V ~ 50 / 60Hz supply, which is
reliably connected to the buildings ground (earth) point.
Due to the input current it is not advisable to use an extension lead, but If an extension lead is
necessary to reach the mains supply, ensure the cross-sectional area of the
wire in the lead is of a sufficient size for the supply of current over the distance re-quired.
If the starter / charger is interrupted or damaged due to heavy impact etc., the bat-tery
should be taken off charge immediately.
SAFETY INSTRUCTIONS
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Warning: Risk of electrical injury or damage!
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
IMPORTANT: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the Starter /
Charger.
Note: Supplementary information.
WIRING DIAGRAM 05548 PWT9500
