13
Now you can remove the tray for a manual tray remove the two screws
Now remove the two screws holding the back of the burner tray in place.
The tray is now free and may be lifted away from the box, lift free of the retaining clips on each side of the
burner tray.
On the slide control option disassemble the linkage by removing the two screws
(shown in diagram below), to the slide control then remove the burner from the
assembly by removing the three screws at the base of the burner tray and undoing
the connecting nut to the isolation tap on the side.
