19
SECTION 8: FITTING OF THE FUEL BED AND GLASS
Place the ceramic matrix onto the burner ensuring that the matrix is sitting securely over the burner tube,
the top section of the matrix sets level on the base section.
Once the fuel bed is in position you can the refit the glass support base bracket and gentle place the glass
into position, then fit the top retaining bracket with the three screws DO NOT over tighten.
Now place back into position the cover plates around the glass as shown below
