LED Definition
As shown from the top to the bottom.
Port
Description
OPS (White)
Shows OPS activity.
Power (Red)
Shows the device is turned on.
2.4GHz (Blue)
Shows 2.4GHz WiFi activity.
WAN (Blue)
Shows the WAN cable is connected.
LAN (Blue)
Shows the cable is connected.
LAN (Blue)
Shows the cable is connected.
LAN (Blue)
Shows the cable is connected.
LAN (Blue)
Shows the cable is connected.
