REV. 02 9 / 30
CHAPTER 5 - TECHNICAL SPECIFICATION
5.1 SIZE AND MAIN FEATURES (Ref. Figure 2)
CAPACITY 3000KG
Max. lifting height 2060mm
Length of the platform 1540 - 1740 mm
Width of platform 550mm
Free width between platforms 800mm
Overall length 1540mm
Overall width 1900mm
Lifting time 60 s
Lowering time 60 s
Compressed air pressure 6 bar – 8 bar
Noise level 80 dB(A)/1m
Working temperature
-10 °C
40 °C
Average weight of package 800g
5.2 ELECTRIC MOTOR
Type ML90L2 G90N4
Voltage 230V/220V-1Ph 400V/380V-3Ph
Power 2.2 KW 2.6 KW
N° Poles 2 4
Speed 2800 rpm 1375 rpm
Motor enclosure type B14
Insulation class IP 54
Motor connection must be carried out referring to the attached wiring diagrams (the figure 5).
The motor direction of rotation is shown in the label placed on the motor.
Before use of the lift, make sure to check if the motor specification shown in the nameplate of
the motor conforms to the local electric supply.
If there is over 10% fluctuation on the electrical power supply，it is suggested to use the voltage
stabilizer to protect the electrical components and system from overloading.
5.3 PUMP
Type Gear
Flow rate 2.0 cm
