32
PARTS LIST
Part no. Description Q´ty
1 Main frame 1
2 Rear stabilizer 1
3 Curved washer Ø8*Ø20*1.5 10
4 Allen screw M8*16 14
5L End cap for rear stabilizer(L) 1
5R End cap for rear stabilizer(R) 1
6 Hex head bolt M8*45 4
7 Pedal ( L ) 1
8 Pedal tube ( L ) 1
9 D type washer Ø50 2
10 Flat washer Ø8*Ø20 4
11 Decorative cover Ø50 2
12 Allen bolt M8*20 4
13 Club knob 4
14 Sleeve 2
15 Hex head bolt M10 2
16 Flat washer Ø50 2
17 Flat washer Ø10*Ø22 2
18 Nylon nut M10 2
19 End cap for front stabilizer ( L ) 1
20 Front stabilizer 1
21 End cap for front stabilizer ( R ) 1
22 Spacer for pedal tube 4
23 Spacer for pedal 4
24 Flat washer Ø8*Ø17 4
25 Bushing for bottom handlebar tube Ø42*Ø13.8 4
26 Bottom handlebar tube ( L ) 1
27 Bushing for bottom handlebar tube Ø42*Ø19 6
28 D type washer Ø42 2
29L Decorative cover ( L ) 2
29R Decorative cover ( R ) 2
30 Decorative cover Ø42 2
31 Self-tapping screw ST5*15 13
32 Front post 1
34 Hollow carriage screw Ø8*20 4
35 Allen bolt M6*12 4
36 Top handlebar tube (L) 1
