Skandika Morpheus - Page 33

33
GB
PARTS LIST
Part no. Description Q´ty
37 Foam grip for top handlebar tube 2
38 End cap 2
39 Foam grip for stationary handlebar 2
40 Stationary handlebar 1
41 Upper computer wire 1
42 Hand pulse sensor 2
43 Flat washer Ø4.2*Ø12 2
44 Self-tapping screw ST4*20 2
45 Cross screw M5*10 4
46 Computer 1
47 Top handlebar tube ( R ) 1
48 Pulse wire 2
49 Bottom handlebar tube ( R ) 1
50 Pedal ( R ) 1
51 Pedal tube ( R ) 1
52 Lower computer wire 1
53 Allen bolt M8*20 1
54 Powder spacer 1
55 Hex head nut M8 1
56 Belt adjusting bolt 1
57 Belt adjusting spring 1
58 Idler wheel assembly 1
59 Self-tapping screw ST5*15 11
60 Sensor wire 1
61 Power wire 1
62 Motor wire 1
63 Motor 1
64 Run disc cover 2
65 Flange nut 4
66 Run disc 2
67 Run disc holder 2
68 Self-tapping screw ST5*10 8
69 Chain cover ( R ) 1
70 Chain cover ( L ) 1
71 Axle 1
72 Belt pulley 1
73 Nylon nut M6 4
