E
B
A
D
C
A . in (520,9 mm)
B . in (490.2 mm)
C . in (119,8 mm)
D . in (75,9 mm)
E . in (206,5 mm)
Specifications
Model Maximum
pressure
Delivery
hose
Weight Delivery hose outlet
external threads
Connecting hose inlet
external threads
Maximum operating
temperature
psi bar in x ft mm x m lbs kg °F °C
21
3
/8 x 9,5 x 15,2 . 15,6
1
/4 in NPTF
1
/4 in NPTF 66
21
1
/2 x 12,7 x 15,2 16,8
1
/2 in NPTF
1
/2 in NPTF 66
Fig. 1
Dimensions
