SKF Multilog IMx-S 16 - Power and Cable Connections

Installation
Mains Power
SKF Multilog On-Line System IMx-S 2 - 3
User Manual – Revision S
In order to attach power cable to the mains power grid, follow the directions below.
• First connect the green-yellow wire to the PE (protective earth) terminal.
• Connect the blue wire to the N (neutral) terminal.
• Connect the brown or black wire to the L1 (line) terminal.
Important - Make sure that the power is turned off before working with the
power cable. Touching the leads of a powered cable can cause serious injuries.
Important - In some countries, the installer must be certified to install equipment
such as an IMx-S.
Important - For permanently connected IMx-S an external all pole power switch
must be installed in order to be able to disconnect the IMx-S from the mains power
grid. The switch must be labelled "IMx-S” or siilar. O/Off positio ust e learly
marked. The switch must be located close to the IMx-S, within operator's easy reach.
Important – The fuse holder CANNOT be used as a mains power disconnect
device.
Important - In order to prevent a hazardous event, mains cable neutral (N) and
line (L1) wires must be secured together with a cable tie (for example, a nylon cable tie
CV-100K) close to the mains power connector.
Important - All externally provided equipment must be evaluated individually
and approved together with IMx-S unit regarding EMC and safety requirements (CE
and ETL). Always consult SKF before using the external mains output.
