Specifications
MODEL MINI Z
ENGINE
Type 120 4-stroke
Details Axial air cooled
Cylinders
1
Displacement cm
3
(in
3
)118(7.2)
Bore mm (in) 60 (2.4)
Stroke
mm (in) 42 (1.7)
Maximum horsepower
RPM
± 100 RPM 3850
Carburetion
Horizontal type,
butterfly valve
Exhaust system Mini Z
DRIVE SYSTEM
Drive pulley type Comet
Driven pulley type 48 teeth sprocket
Drive sprocket diameter mm (in) 81 (3.2)
Number of links 78
Drive chain
Pitch 12.7mm(.50in)
Brake system Mechanical
Track nominal width mm (in) 254 (10)
Track nominal length mm (in) 1749 (68.9)
Track profile height mm (in) 16 (.63)
Tension 35 mm (1-3/8 in)
(1)
Track
Alignment
(2)
66
