12/23
component (contactor) from a master electric
device.
6. R-run / S-stop
The controller is ready for operation after turning
on. It is either in the R-run or W-wait condition in
dependence upon setting of functions of digital inputs
(parameter A19, A21). The controller is switched over in
the S-stop condition after depressing the
stop
/
run
button.
When depressing the button again, the controller will be
switched from the S-stop in R-run or W-wait condition.
7. Setting and saving of parameters
Select the required parameter using the ▼ and ▲
buttons. If it has not been locked (key symbol), the
value of parameter can be modified using the + or –
keys. Press the
enter
button to save, all parameters are
saved in the memory at once. It is recommended to save
in the S-stop status.
First, locked parameters must be unlocked by typing
the password, parameter A41 (Chapter 8.28.).
8. Description of parameters
The controller contains a set of parameters marked
A10 - A41. Parameter numbers do not form a continuous
series of numbers for compatibility with other
controllers.
8.1. A10 Amplitude
The controller controls output voltage amplitude
within the maximum range of 5-100% with 0.5% steps. The
effective value of voltage depends on power supply
voltage. Range of setting is restricted with the value
of the parameter A17 Maximum amplitude and A18 Minimum
amplitude.
8.2. A11 Frequency
The controller controls output voltage frequency
within the range of 20-120 Hz with 0.2 Hz steps.
8.3. A12 Delay ON
A13 Delay OFF
The parameters sense if at least one senor is
connected to the controller monitoring the filling of
To Next Page
