7/23
3. Connection
Connection of external electric components of the
controller may be carried out only by the person with
adequate electro-technical qualification. Connection
may be done only if the controller is disconnected from
the mains.
Caution! Electric charge remains in capacitors
after controller disconnection from the mains. This
electric charge may become a cause of fatal injury! The
lid may be removed only if the controlled has been
disconnected from the mains for at least 60 seconds!
Caution! If the device is used in a manner not
specified by the manufacturer, the protection provided
by the device may be compromised!
3.1. Installation
The controller can be installed either in the
horizontal position or in the vertical position with
outlets facing downward.
Caution! The controller should be mounted to
a mechanically stable part of equipment free of direct
vibrations.
Drill four holes with a drill with diameter of 4.2 mm
in the base plate to which the controller should be
mounted and cut M5 threads in them. The pitch of the
holes is apparent from Fig. 2. Mount the controller
using 4 M5x8 screws with fan washers.
Caution! Washers are needed so when tightened
the layer of elox is cut and the controller is
conductively joined to the body of the machine.
3.2. Lid disassembly
Unscrew four M3 screws mounting the controller lid
and remove the lid (Fig. 4).
