Skipala DIGR-1502/E User Manual

8/23
Fig. 4 – dismantling of the cap
To allow better access to the terminal block, we
recommend dismounting also the part with outlets
(Fig. 5).
Fig. 5 – Removal of the part with outlets
There are connecting terminals under this lid
(Fig. 6).
M3
M3
M3
M3
