FABIA 2000 ³ Body Work
Rear spoilerEdition 10.03
S00.5319.13.20
66-8 page 1
66
66-8 Rear spoiler
Summary of the components - for the
complete rear spoiler (Combi)
1 - Rear spoiler
2 - 3. Brake light
3 - Glue sealing mass
Removing and installing rear spoiler
completely (Combi)
Special tools, test and measuring equipment and
auxiliary items required
♦ Cutting wire with holder (e.g. -V.A.G 1351-)
♦ Glue sealing mass -HHA 381 013-
♦ Cleaning solution -D 009 401 04-
Removing the spoiler
– Cut off the spoiler from the tailgate (cut through the
glue sealing mass).
– Remove the spoiler.
Do not damage the painted surfaces.
Installing the spoiler
– Clean the body and seating area for the spoiler with
cleaning solution -D 009 401 04- while observing the
instructions issued by the manufacturer.
– Spread the glue sealing mass -1- onto the marked
spoiler surface.
– Centre the spoiler on the tailgate.
– Press the spoiler onto the tailgate.
– Secure the correct location of the spoiler using adhe-
sive tape.
– Remove any dirt present using a cleaner.
♦ The glue sealing mass must dry for 2 hours. Do not
drive the vehicle in this time.
♦ Do not drive into the carwash within 24 hours of gluing
on the spoiler.
Summary of the components - for the
complete rear spoiler (RS)
1 - Rear spoiler
2 - 3. Brake light
Note
Note
