SKY-HERO Loki MK2 - UAV and GCS Component Schematics

4
b. UAV and GCS Schematics
RIGHT TOP BUTTONLEFT TOP BUTTON
JOYSTICK 2JOYSTICK 1
ALLOCABLE
BUTTON 1 TO 3
MENU BUTTON
SCREEN POWER BUTTON
DEVICE
BUTTON 1 TO 4
DEVICE BUTTON
LEDs
FOLDABLE
ANTENNA
STRAP ATTACHMENT
POINT
STRAP ATTACHMENT
POINT
RADIO INPUT
PORT
HEADPHONES
PORT
AUDIO/VIDEO
OUT PORT
SD CARD
SLOT
CHARGING
USBC
CHARGING
LED
