SKY-HERO Loki MK2 - Ground Control Station Menu Navigation; Pre-Flight Checks and Compliance

7
c. GCS Menu Navigation
d. Before First Flight
Navigating the menu is accomplished using the Menu Button and the Joystick 2 only.
•
ENTER MENU
: Press the Menu Button, which enables you to enter/exit the menu at any time
•
SCROLL
: Use Joystick 2 to move up or down, which enables you to select the submenus
•
ENTER
: Push Joystick 2 to the right to enter the submenu
•
CONFIRM
: Push Joystick 2 to the right to confirm a choice in the menu/submenu
•
BACK
: Push Joystick 2 to the left to exit the current submenu and go back one level
CAUTION: YOUR LOKI MK2 SYSTEM COMES READY TO USE AND HAS BEEN TESTFLOWN IN OUR FACILITY.
HOWEVER, SOME SETTINGS MIGHT NEED TO BE ADJUSTED TO GUARANTEE THE BEST PERFORMANCES FOR
YOUR USER CASES.
I. Compliance
These settings allow adjustement of the power levels of both UAV control and video signal. By default, FCC
or CE compliant mode is used (depending on your region). However, you may want to change these settings
to «OPEN» in order to increase the general performances of your system. When switching to «OPEN», the
Control will automatically be adjusted up to 250 mW; while the Video Power will need to be adjusted in the
Video Power sub menu. Please refer to your local regulations before applying these changes.
a. Control
b. Video
Mode Max Power Frequencies
FCC 100 mW 915 MHz
CE 25 mW LBT 868 MHz
Open 250 mW 868/915 MHz
Mode Max Power Number of channels
FCC / CE 25 mW 8
Open 350 mW 37
