8
II. Video Channel
III. Video power
Select the frequency you want to use for your audio video transmission. Be sure to use different frequen-
cies when several devices are used during a same mission to avoid interference between devices. The UAV
paired on Device Button 1 will be listed as Device 1, the UAV paired on Device Button 2 listed as Device
2, etc. By default, the system is limited to 8 channels (5725 MHz to 5865 MHz) and to Video Power 1 (=25
mW). However, when switching to «OPEN» in the Compliance menu, more frequencies and higher power
levels are accessible. This mode is accessible via the “Compliance \ Video” menu. As those additional fre-
quencies and power levels could be subject to special authorizations or licenses, please refer to the local
regulation body for accurate information.
The Loki MK2 system uses an analog video transmission which offers greater reliability
while eliminating screen freezing, latency, and reboot time. The system broadcasts
around the 5.8 GHz frequency band, producing good performance even when multiple
devices are connected.
You can select a specific value for each device used. Please note that Video Power 0 is used for ultra short
range to control functions without disturbing other users.
Level Video power
0 1 mW
1 25 mW
2 250 mW (“OPEN” mode only)
3 350 mW (“OPEN” mode only)
IV. Video Scrambling
CAUTION: USING SCRAMBLING WILL LIMIT THE MAXIMUM RANGE YOU CAN REACH WITH YOUR VIDEO SYS-
TEM AS THE GLITCHES FROM THE ANALOG SIGNAL WILL HAVE AN INFLUENCE ON THE WHOLE PICTURE’S
QUALITY.
This setting is common to all connected devices
Turning scrambling ON will enable you to make your video signal unreadable by non-Loki MK2 users.
FCC settings
Name Frequency (MHz)
A1 5865
A2 5845
A3 5825
A4 5805
A5 5785
A6 5765
A7 5745
A8 5725
Open settings
Name Frequency (MHz) Name Frequency (MHz) Name Frequency (MHz) Name Frequency (MHz) Name Frequency (MHz)
A1 5865 E1 5705 SH10 5251 SH18 5547 SH26 5843
A2 5845 E2 5685 SH11 5288 SH19 5584 SH27 5880
A3 5825 E3 5665 SH12 5325 SH20 5621 SH28 5917
A4 5805 E4 5645 SH13 5362 SH21 5658 SH29 5954
A5 5785 E5 5885 SH14 5399 SH22 5695 SH30 5991
A6 5765 E6 5905 SH15 5436 SH23 5732
A7 5745 E7 5925 SH16 5473 SH24 5769
A8 5725 E8 5945 SH17 5510 SH25 5806
