SKY-WATCHER S11670 User Manual

REFRACTOR
2
MANUAL EQ5 PRO
5
B
C
D
E
F
G
H
J
K
M
L
I
2
1
3
6
7
8
9
11
(150mm/1200mm)
10
12
13
4
A
EQ5
TUBE
A. Dust Cap/Mask
(Remove before Viewing)
B. Sun Shade
C. Objective Lens
D. Telescope Main Body
E. Piggyback Bracket
F. Tube Rings
G. 8x50 Viewfinder or
Red Dot Finder
H. Finderscope Bracket
I. Alignment Screw
J. Eyepiece
K. Diagonal
L. Focus Tube / Draw Tube
M. Focus Knob
MOUNT / TRIPOD
1. Polarscope Holder
2. Altitude Adjustment T-bolts
3. Azimuth Adjustment Knob
4. Counterweight Rod
5. Counterweight
6. Counerweight Thumb
Screw
7. R.A. Control Knob
8. R.A. Lock Knob
9. Dec. Lock Knob
10. Dec. Control Knob
11. Mounting Plate
(150mm/1200mm)
12. Accessory Tray
13. Tripod Leg
