SKY-WATCHER S11670 User Manual

REFLEC TOR
MANUAL EQ5 PRO
12
13
EQ5
TUBE
A. Dust Cap/Mask
(Remove before Viewing)
B. Focus Tube
C. Red Dot Finder or
8x50 Viewfinder
D. Eyepiece
E. Focus Knob
F. Piggyback Bracket
G. Tube Rings
H. Telescope Main Body
I. Primary Mirror Position
MOUNT / TRIPOD
1. Mounting Plate
(200mm/1000mm)
2. R.A. Control Knob
3. Polarscope Holder
(not shown)
4. Altitude Adjustment T-bolts
5. Azimuth Adjustment Knob
6. Counterweight
7. Counerweight Thumb
Screw
8. Counterweight Rod
9. R.A. Lock Knob
10. Dec. Lock Knob
11. Dec. Control Knob
12. Accessory Tray
13. Tripod Leg
A
B
C
D
E
F
1
(200mm/1000mm)
2
3
4
5
6
7
8
9
10
11
G
I
H
3
