SKY-WATCHER S11670 - Page 4

MAKSUTOV & SCHMIDT-CASSEGRAIN
4
MANUAL EQ5 PRO
EQ5
TUBE
A. Dust Cap/Mask (Not shown
remove before viewing)
B. Red Dot Finder or
8x50 Viewfinder
C. Focus Locking Screw
D. Eyepiece
E. Diagonal
F. Focusing Knob
MOUNT / TRIPOD
1. R.A. Lock Knob
2. Dec. Flexible Control Cable
3. Polarscope Holder /
Polarscope (not shown,
optional)
4. Altitude Adjustment T-bolt
5. Azimuth Adjustment Knobs
6. Counerweight Locking
Thumb Screw
7. Counterweight Rod
8. Dec. Lock Knob
9. Dec. Setting Circle
10. Accessory Tray
11. Hight Adjustment Clamp
10
11
A
B
C
D
E
1
2
3
4
F
9
8
7
6
5
