13
PART IV: Assembling Your Telescope
4.2 Eyepiece Assembly
1. Inserting eyepiece for Maksutov(Fig.4.2.1a)
Loosen the thumbscrew on the end of the focus tube.
Insert the diagonal into the focus tube and re-tighten the thumbscrew to hold the diagonal
in place.
Loose the thumbscrews on the diagonal.
Insert the desired eyepiece into diagonal and secure by re-tightening thumbscrews.
reector
Maksutov
Fig.4.2.1a
Unscrew the thumbscrews on the end of the focus tube to remove the black plastic end-
cap.
Insert the desired eyepiece then re-tighten thumbscrews to hold the eyepiece in place.
Fig.4.2.2a

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SKY-WATCHER VIRTUOSO GTi and is the answer not in the manual?

SKY-WATCHER VIRTUOSO GTi Specifications

General IconGeneral
TypeReflector
Focal Ratiof/5
Mount TypeAlt-Azimuth
GoTo SystemYes
App ControlYes
Wireless ConnectivityWi-Fi
Motor DriveYes
Tracking RatesSidereal, Lunar, Solar
GPSNo
App Control SoftwareSynScan App
Payload Capacity5 kg
Power Supply12V DC
TripodAluminum
