Sky Hub - Connecting Sky Hub for Pre-filtered Socket; Connect DSL to Pre-filtered Socket; Connect Power to Hub and Mains

6 7
Plug the blue end of
the black power cable
into the blue port of
your Sky Hub.
Plug the other end
directly into the mains
and switch on.
Plug one of the purple
ends of the grey DSL
cable into the left port
of your pre-filtered
master socket.
Plug the other purple
end of the grey DSL
cable into the purple
port of your Sky Hub.
Unplug your
DSL cable from
your socket.
Unplug
Avoid plugging into a
mains extension block as
it reduces performance.
Plug in your Sky Hub
For best performance leave your Sky Hub permanently
switched on. Your Sky Hub may feel warm from time to
time, this is perfectly normal and no cause for concern.
Continue to page 8 >
Continued from page 2
