Specifications Section 7 – Technical Diagrams and Specifications
7.4 Specifications
Model SJ46 AJ+
Platform Size
Total Platform Length (Outside)
1.52 m / 1.83 m
(60 in / 72 in)
Total Platform Depth (Outside) 0.76 m (30 in)
Height
Working 15.93 m (52 ft 3 in)
Platform Elevated 14.10 m (46 ft 3 in)
Drive (Maximum) Driveable at all heights
Stowed 2.06 m (6 ft 9 in)
Length
Overall with Platform
6.35 m (20 ft 10 in)
Width
Outside Standard Tires
2.29 m (7 ft 6 in)
Weight
With Foam-filled Tires
6,000 kg (13, 200 lb)
Platform Rotation 175°
Horizontal Reach 7.54 m (24 ft 9 in)
Wheelbase 2.03 m (6 ft 8 in)
Turret Rotation 360°
Turret Tailswing 0
Maximum Gradeability 45%
Ground Clearance Under Axle 0.33 m (13 in)
Turning Radius
Inside
4WD
1.50 m (4 ft 11 in)
Outside 4.34 m (14 ft 3 in)
System Voltage 12 V DC
Battery
Type Lead/Acid
Cold Cranking Amperes 950 A
Operating Times
Main Boom Up 29 - 32 seconds (approx.)
Main Boom Down 27 - 30 seconds (approx.)
Riser Up 24 - 30 seconds (approx.)
Riser Down 30 - 35 seconds (approx.)
Fly Boom Extend 10 - 16 seconds (approx.)
Fly Boom Retract 25 - 30 seconds (approx.)
Jib Up 18 - 24 seconds (approx.)
Jib Down 10 - 16 seconds (approx.)
Turret Rotate 70 - 90 seconds (approx.)
Platform Rotate 5 - 9 seconds (approx.)
Driving Speeds
Travel Speed (Lowered Travel
Position)
7.7 km/h (4.8 mph)
Travel Speed (Elevated Travel
Position)
0.8 km/h (0.5 mph)
