SJ46 AJ+ 213208ABA
91
Maximum platform capacities (evenly distributed) Section 7 – Technical Diagrams and Specifications
7.7 Maximum platform capacities (evenly distributed)
7.8 Floor loading pressure
Model
Weights Pressures
MEWP Weight
Max Weight per
Wheel** LCP*** OFL***
kg lb kg lb kPa psi kPa psf
SJ46 AJ+
Min* 6380 14060 2041 4500 884 128 9.6 200
Max* 6680 14720 3000 6600 1090 158 10 209
1870AA
Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel Load is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the floor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath
the chassis. This has been calculated by dividing the MEWP weight by the overall floor area occupied by the MEWP (on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must be able to withstand
more than the values indicated above.
SJ46 AJ+
Regular Platform Capacity
300 kg (660 lb)
2 persons (maximum
number of personnel)
400 N (manual side force)
Derated Platform Capacity*
272 kg (600 lb)
1 person (maximum
number of personnel)
200 N (manual side force)
Wind rating 12.5 m/s (28 mph)
Tilt cutout setting (side-to-side x front-to-back) 5 degrees x 5 degrees
1869AA
*NOTE: Refer to Section 3 for the capacity derate switch operation.
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
