SJ46AJ SJ51AJ SJ63AJ
December 2007 Page 111
Section 2 - Operation Labels
Model SJ63AJ
No. Label Pictorial Description
1
Harness Anchorage
Anchor safety belt/harness tethers here.
2
Manual Box
Indicates location of operating manual.
3
kg
( lb)
Platform Capacity*
Rated work load when operating on a level ground. Rated
work load includes the weight of both personnel and material,
and maximum number of people in each conguration. Do not
exceed total weight or maximum number of people. Load platform
uniformly.
*Platform capacity will vary over different MEWPs.
4
Horizontal Load Rating
Apply no more than indicated side load. Operate below indicated
wind speed only.
Platform (Continued)
Clearance Requirements
1 2 3 14
68
5
7 9
To Next Page
