SJ46AJ SJ51AJ SJ63AJ
December 2007 Page 73
Table 4.4 Tire/Wheel Specifications
SJ 46AJ SJ 51AJ SJ 63AJ
Tire Size 315/55 D20 315/55 D20 355/55 D625
Type Foam-filled Foam-filled Foam Filled
Tire Ply Rating 12 12 14
Wheel Nuts Torque 393 Nm 393 Nm 393 Nm
1052AA_AS
IMPORTANT
For proper function of each axle differential, all four wheels must have same tire size installed at
all times. Failure to comply with this requirement will reduce the life of the differentials and reduce
overall mobility of MEWP.
Table 4.5 Maximum Platform Capacities
SJ 46AJ SJ 51AJ SJ 63AJ
227 kg 227 kg 227 kg
2 Persons 2 Persons 2 Persons
Maximum Wind 12.5 m/s 12.5 m/s 12.5 m/s
Maximum Side Force 400 N 400 N 400 N
Tilt Cutout Setting 5 degrees x 5 degrees 5 degrees x 5 degrees 5 degrees x 5 degrees
1053AA_AS
Total Capacity *
