Skyjack SJ86T User Manual

Page 56 December 2007
SJ 86T
Start Operation Section 3 - Operation
3.7-2 To Rotate Platform Using Base Control
Console
1. Activate function enable “ ” by selecting and
holding start/function enable/emergency power
switch to function enable position.
2. Push platform rotation switch to either “ ” left or
“ ” right position. Release switch to stop.
3.7-3 To Rotate Turret Using Base Control
Console
WARNING
When rotating the turret, ensure that there
are no personnel or obstructions in the
path of rotation, including blind spots.
1. Activate function enable “ ” by selecting and
holding start/function enable/emergency power
switch to function enable position.
2. Push turret rotation switch to either “ ”
clockwise or “ ” counterclockwise position.
Release switch to stop.
NOTE
Turret can be rotated continuously
360 degrees.
3.7-4 To Move Jib Up and Down Using Base
Control Console
1. Activate function enable “ ” by selecting and
holding start/function enable/emergency power
switch to function enable position.
2. Push jib up/down switch to either “ ” up or
“ ” down position. Release switch to stop.
3.7-5 To Raise or Lower Main Boom Using Base
Control Console
NOTE
Maximum platform capacity varies with
boom position. Indicator lights on the base
and platform control consoles indicate
whether platform is in the “high” or “low”
capacity zone.
1. Activate function enable “ ” by selecting and
holding start/function enable/emergency power
switch to function enable position.
2. Push main boom raise/lower switch to either
“ ” raise or “ ” lower position. Release
switch to stop.
3.7-6 To Extend or Retract Fly Boom Using Base
Control Console
NOTE
Maximum platform capacity varies with
boom position. Indicator lights on the base
and platform control consoles indicate
whether platform is in the “high” or “low”
capacity zone.
1. Activate function enable “ ” by selecting and
holding start/function enable/emergency power
switch to function enable position.
2. Push y boom extend/retract switch to either
“ ” extend or “ ” retract position. Release
switch to stop.
3.7-7 To Level Platform Using Base Control
Console
1. Activate function enable “ ” by selecting and
holding start/function enable/emergency power
switch to function enable position.
2. Push platform leveling override switch to either
“ ” up or “ ” down position. Release
switch to stop.
3.7-8 To Operate Using Emergency Power
Switch at Base Control Console
This is a momentary-type switch. This switch allows
all functions except the drive function to operate in the
event of engine malfunction. Refer to Section 2.6 for the
emergency lowering procedure.
