Skyjack SJ86T User Manual

Page 64 December 2007
SJ 86T
Diagrams Section 3 - Operation
3.11 Technical Diagrams
-4.5
-1.5
0
1.5
3
4.5
6
7.5
9
10.5
12
13.5
15
16.5
18
19.5
21
22.5
24
25.5
27
-3
28.5
-1.5
25.5
-3
2422.519.5
18
16.51513.51210.597.564.531.50 21
Meters
Figure 3-11. Reach Diagram - SJ86T
72.5 degrees
28 ft. 3 in. (8.61 m)
86 ft. (26.2 m)
65 degrees
92 ft. (28.0 m)
105 in.
2667 mm
12 degrees
16 in. (40.64 cm)
66 in. (167.64 cm)
10 ft. 8 in. (3.25 m)
13.25 in. (33.66 cm)
283 in. (718.8 cm)
245 in. (622.3 cm)
98 in. (248.92 cm)
96 in./72 in.
36 in. (91.4 cm)
56 in.
[1422.4 mm]
360 degrees
63.7 in. (161.8 cm)
60 in. (152.4 cm)
76 ft. 10 in. (23.42 m)
(243.8 cm/182.9 cm)
170 degrees
Figure 3-12a. Dimensions - SJ86T
