Skyjack SJ86T User Manual

SJ 86T
December 2007 Page 57
Section 3 - Operation Start Operation
3.7-9 To Activate Platform Control Console
1. In engine compartment, turn main power
disconnect switch to “ ” on position.
2. On base control console, turn off/base/platform
key switch to “ ”platform position.
3. On base control console, pull out “ ” emergency
stop button.
WARNING
Ensure that you maintain three points of
contact to mount/dismount the platform.
WARNING
DO NOT operate any control on operator’s
control console without proper fall
protection secured to the designated
location in the platform. Failure to avoid
this hazard could result in death or
serious injury.
4. Enter platform and close gate/drop bar.
5. Attach body harness lanyards of each occupant
to fall protection anchorage points. Rated for one
(1) person per anchorage.
6. On platform control console, pull out “ ”
emergency stop button.
7. Select “ ” start position from engine start/on/off
switch until engine starts.
NOTE
Maximum platform capacity varies with
boom position. Indicator lights on the base
and platform control consoles indicate
whether platform is in the “high” or “low”
capacity zone.
WARNING
DO NOT over crank the starter. If engine
fails to start after multiple attempts,
contact competent/qualified repair
personnel.
NOTE
Engine will not start if you are pressing
down on the footswitch.
8. Select desired engine RPM using throttle switch:
“ ” high or “ ” low.
WARNING
• DO NOT drive or steer the MEWP when the
platform position does not allow you a clear
view of the base.
• Your area of operation should be cordoned
from other personnel or equipment.
3.7-10 To Drive Forward or Reverse Using
Platform Control Console
CAUTION
When you are in the platform and
positioned over an axle, the direction
you are facing will be forward.
1. Depress and hold footswitch.
2. Push and hold drive/steer controller in this
direction “ ” to drive forward or “ ” to drive
backward.
3. Release controller handle to stop.
CAUTION
The drive orientation can change when
the turret is swung 90 degrees off center
of the normal driving position (roughly
when boom is swung past the rear tire).
Drive re-orientation will not occur while
driving and rotating until the joystick
is released for 6 seconds or when the
footswitch is released.
CAUTION
• When driving on a slope:
• Torque Switch MUST be in high torque mode.
• DO NOT exceed the rated gradeability listed
in Table 4.2a.
• Ensure fuel level is above half to avoid a
possible stall condition.
