Introduction
· 02
D250
Please read this entire operating manual completely and attentively before using
this product, as it covers a wide range of information on operating and safety. Or
please do use this product in company with a specialist!
Output Socket 4mm Banana Plug
Balance Lead Socket
USB Port
Temperature Sensor Port
Output Socket
4mm Banana
Plug
Balance Lead Socket
Temperature Sensor Port
LCD Display
Cooling Fan
Power
Switch
AC Socket
100-240V
Resume or Start
Charge Processes
Scroll Through the
Main Menu Stop Any
Charge Processes
Alter Values
See the Status of Individual
Cells in Balance Charge Mode
DC Input 11-18V
DC Output 13.8V
DC Output Power
Level Indicator
Micro USB Port
for PC Link
