Features
Skytec Professional stereo audio amplifier featuring high output power and excellent value for money.
The SKY-MKII range of amplifiers are ideal for the starting DJ, smaller fixed installations in pubs,
clubs canteens etc. or as a complement in larger disco installations.
Outstanding sound quality
Stereo and bridge mode
Signal & Clip indication for each channel
Inputs via RCA & 6.3mm jack
Speaker NL4, 6.3mm Jack & binding post
outputs
Front Panel Features
1. On/Off Switch.
For switching the amplifier on and off. Always adjust the volume down to its minimum before
switching this amplifier on.
2. Cooling Vents.
Front to rear forced airflow.
3. Volume Controls.
These controls adjust the volume level of both channels. Turn slightly to the left when the clip
indicators (4) light up.
4. Signal indicators.
Three orange LEDs indicate the amplifiers output signal levels.
5. Clip Iindication.
These LEDs will light up when one or both channels are on max power. It can occur that these
LEDs will lit up now and then, this is not a problem. But if it lights up continually you need to adjust
the volume down, otherwise permanent damage to equipment might occur
6. Protect Indication.
When on any given point, something damaging might occur to your amplifier, it will switch in protect
mode. The amplifier will disconnect the point where the damage is about to occur and switch on the
protection led to indicate to you that something is wrong. Reasons might be: Bad ventilation,
A low impedance (< 4 Ohm), Defect fan(s), A short circuit in cables.
7. Bridge Mode Indication.
8. Power Indication.
This clear blue indicator will light when the amplifier is turned on.
