EXTERNAL SCHEMATIC AND INSTALLATION
Front Panel
Note: The graphics are for representation only.
-6-
7.Standby Button
(Functions as OK button when main menu or source menu shows on the TV.)
1.Power Indicator / Remote Sensor
2.Speakers
3.Program Up/Down Button
4.Volume Up/Down Button
5.Menu Button
6.Source Button
7
6
5
4
3
221
Note: This model has two kinds of silkscreen on the front panel, one is symbol
such as +/- indicating volume up/down, the other is character such as VOL+/VOL-
indicating volume up/down.
