SkyZone M5F - Specifications; BAND;CHANNEL Table; Package Included

Specifications
Package Included
1. Monitor*1
2. 5.8GHz 2dB antennas*2
3. Video/Audio Cable*1
4. USB-C Cable*1
5. XT60-DC5.5*2.1 Power Cable*1
6. User Manual*1
1
BAND/CHANNEL table
BAND/CH CH 1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
A 5865M 5845M 5825M 5805M 5785M 5765M 5745M 5725M
B 5733M 5752M 5771M 5790M 5809M 5828M 5847M 5866M
E 5705M 5685M 5665M 5645M 5885M 5905M 5925M 5945M
F 5740M 5760M 5780M 5800M 5820M 5840M 5860M 5880M
R 5658M 5695M 5732M 5769M 5806M 5843M 5880M 5917M
L 5362M 5399M 5436M 5473M 5510M 5547M 5584M 5621M
BAND/CH table
Sensitivity
-98dBm±1dBm
Antenna port
2 X SMA-K,50ohm
Specification
Screen
Resolution
Receiver
Language
Power
PowerConsumption
DVR
Endurance
M5F
900 Lum High brightness LCD
800*480
5.8Ghz 48 CH SteadyView Fusion Receiver
Chinese/English
DC 6.5-25.2V/USB 5V/18650 Lion
12V/520mA 6.24W
MJEPG 60FPS, SD Max 128Gb
1.5 Hour（16850，3000mAh ）
