Quick Start Guide
1.Install the antenna and 18650 Battery.
2.short press the power button then hold power button for 3s to power on,
3.short press the power button, then hold the power button 3s to shut down..
Band /Channel / Receiver mode setting
1. Press the wheel, then roll wheel to change channel, press the wheel again switch to Band setting
then roll the wheel to change the Band. Press wheel again to select diversity or Mix mode . mode,
2.No wheel operation for 3 seconds，RF setting will quit the channel setting mode.
3. Hold the wheel to pop up search menu, press the wheel to start auto search, after searching all the
frequency, receiver will work on the strongest signal. Roll the wheel to manually select the channels,
hold the right wheel to quit searching.
Sometime the auto search channel is not accurate, user may need manually select the channel.
Receiver Mode
MIX1: Mix1 mode provides basic fusion processing to reduce excessive intervention of the circuit on
the picture
MIX2: Mix2 mode improves synchronization stability, especially under weak signal to maximize
synchronization and lock video
MIX3: Mix3 mode enhances the synchronization signal on the basis of Mix2, maximizes the stability
of the video image, and maximizes compatibility with other display devices. In this mode, the
brightness of the video signal will be reduced
DIV: Div mode, the fusion processing will be turned off, and the receiver will work in the traditional
diversity receiving mode, and the audio and video signal output corresponding to the channel
with the highest RSSI intensity will be selected.
Brightness
· Roll the wheel to adjust the brightness of the screen.
