Slant/Fin BOILERS - BURNER DATA - BECKETT CF-375 BURNERS FOR PACKAGED BOILERS ONLY

L
IBERTY II
15
BURNER DATA – BECKETT CF-375 BURNERS FOR PACKAGED BOILERS ONLY
(
For knocked-down & boiler burner units see publication no. L-42KB)
LD-60 CF-375 2.60 2.25 45˚ P HAGO 135 10 3 1
LD-60 CF-375 2.85 2.25 45˚ P HAGO 160 10 2 2
LD-70 CF-375 3.00 2.5 45˚ SS HAGO 145 10 4 3
LD-70 CF-375 3.10 2.5 45˚ SS HAGO 155 10 4 4
LD-70 CF-375 3.35 2.75 45˚ B DELEVAN 148 10 4 5
B
oiler
Model
Nozzles
B
urner
Model
*
Firing Rate
(GPH)
Size
(GPH)
Angle &
Type MFG
Oil Pump Pressure
Setting (PSIG)
Air Shutter
Setting
†
Air Band
Setting
Head
Setting
† Air shutter and air band settings shown are approximate ONLY.
See START-UP page 8.
* All burner models shown are single stage.
