Slant/Fin VSPH-60 - Dimensions, Rating and Orifice Sizes; Ratings and Dimensions

VI
CTORY VSPH Models
2
NOTE: Height dimensions increase by
1
1
⁄2" and depth increases to 28
1
⁄2" when
combustible floor kit is used.
Natural #49 50 50 50 51 51 51 52 52 52
Propane #57 58 59 59 60 60 61 62 63 63
VSPH-60 60,000 3 11
1
⁄8"17
3
⁄8"
VSPH-90 90,000 4 14
1
⁄8"20
3
⁄8"
VSPH-120 120,000 5 17
1
⁄8" 23
3
⁄8"
VSPH-150 150,000 6 20
1
⁄8"26
3
⁄8"
VSPH-180 180,000 7 23
1
⁄8"29
3
⁄8"
Boiler
Model
No. of
Sections
Input
Btuh
A
B
Gas
Type
2000 3000 4000 5000 6000 7000 8000 9000 10000
Orifice
Size for
Sea Level
Orifice Sizes for High Altitudes
Includes 4% Reduction for Each 1000 Feet
Ele
vation — Feet
Orifice sizes indicated for sea level above are factory installed in boiler unless otherwise specified by the local authority. Orifice
table is based on a higher heating value between 1000 Btuh and 1010 Btuh for Natural Gas (See page 20, if local higher heat-
ing value exceeds these numbers). See page 20, for burner input adjustment.
RATINGS AND DIMENSIONS
Figure 1. Dimensions data
Gas Orifice Size
Victory VSPH boiler
