BATTERY L.E.D. INDICATORS
The Battery LED lights on the control panel will indicate the current battery power level.
•
When all 4 lights are green, it means the battery is fully charged. As the battery power is being
used, the green lights will decrease to 3 green lights, then 2, and finally to 1 green light, indicating
a decreasing battery power level from full to medium to low.
•
If only 1 yellow light is present, it indicates that the battery power is now low.
•
Finally, if only 1 red light is illuminated, it signals that the battery is in a very low state and needs to
be recharged as soon as possible.
OSCILLATOR L.E.D.
The Oscillator LED INDICATOR is GREEN to indicate that the Oscillator is connected and switched on
after pressing the Oscillator “ON / OFF” button (lower button) on the remote control or activating it
manually.
Oscillator L.E.D
Battery L.E.D.’s Indicator
15
Slinger Bag User Guide - Pickleball 2/2023
