machine parts list
12
ITEM DESCRIPTION PART # QTY
1 FRAME 07305 1
2 PRESSURE PLATE 07304 1
3 M5 X 25 FPSSS UH0552 6
4 M5 NUT UH4605 6
5 MOTOR ASSEMBLY, 120V 054001 1
MOTOR ASSEMBLY, 220V 054002
6 GEAR RACK 07323 1
7 M6 X 25 SHCS UH0648 2
8 M6 LOCK WASHER UH2062 3
9 MOTOR CORD 07420 1
10 STRAIN RELIEF 0151064 1
11 POWER CORD, 120V 0012180 1
POWER CORD, 220V-AS SPECIFIED
12 M4 X 16 FHSCS UH0428 1
13 M4 LOCK WASHER UH2046 1
14 M4 NUT UH4604 1
15 SAFETY STRAP LINK 06797 1
16 MAGNET ASSEMBLY 07316 1
17 M8 X 30 SHCS UH0814 2
18 M8 LOCK WASHER UH2082 4
19 M8 X 25 SHCS UH0812 2
20 CONTROL PANEL ASSEMBLY, 120V 07310P 1
CONTROL PANEL ASSEMBLY, 220V 07312P
21 PINION HUB 07320 1
22 SPOKE HANDLE 07319 3
23 HUB WASHER 07306 1
24 M6 X 20 FHSCS UH0628 2
25 CUTTER GUARD 07345 1
26 GUARD SLIDE 07346 1
27 M4 X 12 SHCS UH0422 2
28* COOLANT BOTTLE ASSEMBLY 0151511 1
29 ARBOR ASSEMBLY 05MT800S 1
30 SELF LUBRICATING SLEEVE 07375 2
31 GIB ADJUSTMENT LABEL 07376 1
32 BACK REST 07377 1
33 M6 X 16 SHCS UH0624 2
34 M6 X 16 FHSCS UH0618 1
35 M6 NUT UH4606 1
36 LEFT SLIDE INSERT STRIP 054160 1
37 RIGHT SLIDE INSERT STRIP 054162 1
38* COOLANT BOTTLE CONNECTOR 07327 1
Rev. D
* Part 0151513 includes item 28 & 38
