15
motor parts list
ITEM DESCRIPTION PART # QTY
1* GEAR CASE 07458 1
2 LIP SEAL 07367 1
3 NEEDLE BEARING UH3220 1
4 SPINDLE SEAL 04807 1
5 SPINDLE SEAL 04805 1
6 EXTERNAL RETAINING RING UH4036 1
7 BALL BEARING UH3072 1
8 MOTOR SPINDLE 07368 1
9 INTERNAL RETAINING RING UH4157 1
10 KEY 07467 1
11 GEAR 07448 1
12 EXTERNAL RETAINING RING UH4020 1
13 NEEDLE BEARING UH3216 1
14 THRUST WASHER 07426 1
15 GEARSHAFT 07427 1
16 GEAR 07428 1
17 EXTERNAL RETAINING RING UH4018 1
18 NEEDLE BEARING UH3030 1
19 NEEDLE BEARING UH3018 1
20 OVERLOAD LABEL 07374 1
21 PINION SHAFT 07439 1
22 KEY 07438 1
23 DUAL GEAR 07440 1
24 NEEDLE BEARING UH3015 3
25 BALL BEARING UH3021 2
26 PINION SHAFT 07432 1
27 KEY 07433 1
28 DUAL GEAR 07434 1
29 GEARSHAFT 07446 1
30 GEAR 07444 1
31 WOODRUFF KEY 04564 1
32 HELICAL INPUT GEAR 04582 1
33 SHIFT FORK 07357 2
34 SHORT SHIFT PIN 07356 1
35 SHIFT LEVER I 07450 1
36 ROLL PIN UH4205 2
37 SPRING 04591 2
38 SHIFT DRIVE PIN 04524 2
39 M5 LOCK WASHER UH2056 2
40 M5 X 35 SHCS UH0558 2
41 SHIFT LEVER LABEL 04514 2
42 M3 X 5 CRPHMS UH0300 4
43 LONG SHIFT PIN 07343 1
44 SHIFT LEVER II 07424 1
45 SNAP BUSHING 07441 3
ITEM DESCRIPTION PART # QTY
46 SPECIAL WASHER 07443 1
47 M5 X 12 DOWEL PIN UH4200 1
48 GEARBOX GASKET 04593 1
49 GEAR CASE COVER 07442 1
50 M8 LOCK WASHER UH2083 4
51 M8 X 40 SHCS UH0820 4
52 SPEED RANGE LABEL 07422 1
53 BEARING HOUSING 07445 1
54 M6 X 20 SHCS UH0640 1
55 M5 X 16 DOWEL PIN UH4201 1
56 FIELD HOUSING 054074 1
57 FIELD CASE COVER 054061 1
58 WIRING DIAGRAM LABEL 054062 1
59 INTAKE LOUVER 054070 2
60 BRUSH HOLDER 04551 2
61 MOTOR BRUSH 04549 2
62 BRUSH CAP 04552 2
63 FIELD SLEEVE INSULATOR 04558 1
64 FIELD INSULATOR SCREW 04557 4
65 FIELD, 120V 04555 1
FIELD, 220V 04556
66 M4 LOCK WASHER UH2044 2
67 M4 X 60 SHCS UH0438 2
68 FAN SHROUD 054079 1
69 UPPER ARMATURE WASHER 04560 1
70 BALL BEARING UH3021 1
71 ARMATURE, 120V 04553 1
ARMATURE, 220V 04554
72 KEY 07435 1
73 BALL BEARING UH3039 1
74 CIRCUIT BOARD OVERLOAD 054067 1
75 PIPE HANDLE HOLE PLUG 054011 1
76 MOTOR TAG, 120V 054057 1
77 DRIVE SCREW UH1002 2
78 CIRCUIT BOARD INSULATOR 054012 2
79 M3 X 10 CRPHTCS UH0312 8
80 M4 LOCK WASHER UH2044 4
81 M4 X 8 CRPHMS UH0400 4
82 M6 X 12 FPSSS UH0612 2
83 M5 X 16 CROHMS UH0528 4
84 LED SOCKET 054054 1
85 LED INDICATOR 054085 1
86 INTERNAL RETAINING RING UH4142 1
87 M3 X 8 CRPHMS UH0306 1
88 M3 LOCK WASHER UH2036 1
Rev. D
*Note: Order 07459 for complete Gear Box assembly
